Fused Silica Window D113*3mm Thk AR/AR@1075-1080 Protective Windows For Fiber Welding Machine

$1.00$13.09

High transmission, low absorption, AR coatings, several diameters and thicknesses
Diameter Tolerance:+/-0.1mm
Thickness Tolerance:+/-0.05mm
Chamfer/Bevel:0.25*45°
Flatness:1/2 lambda per inch @633nm
Clear Aperture:>=85%
Surface Figure:<2 per 1″ Dia
Coating: customized available
Surface Quality:40- 20 scratch and dig

SKU: N/A Category: Tags: ,
TOP SELL PRODUCTS

Materials: Fused Silica, Fused Quartz

Trumpf®

134×3 mm mostly used for welding PFO3D Trumpf T1064 VIS Q

55×1,5 mm ALO3 Scansonic, Ref No.:632713–117 759720, 1584792

34× 5 mm Trumpf cutting, Trudisk cutting 1614767, 632251–117, 1514767

Precitec®

50×2 mm welding High Yag, Precitec  P0251–1419–00001, P0251–1070–00001, P0251–040–00001 P0795–1201–00 OG Y D50 d2 1064

22,35×4 mm Precitec cutting P0589–360–00002, P0589–360–00001, Adige tube P058936000001, 21,5×2 mm OG Y D21.5 d2 P0588–1022–00001

37×7 mm P0595–61551

30×1,5 mm OG Y D30 d1,5 P0253–1034–00001

25×4  mm IPG 500 W, FIBER

Bystronic®

36×5 mm 10045746

Raytools®

Cover Glass (TOP) 211LCG0020,Cover Glass (Middle / Bottom) 211LCG0037

laser-consamables

Fiber windows parameters:

Model Dia(mm) Thickness(mm) Material
1064-D20-T2 20 2 (SiO2) Quartz
1064-D20-T3 20 3 (SiO2) Quartz
1064-D20-T5 20 5 (SiO2) Quartz
1064-D22.35-T4 22.35 4 (SiO2) Quartz
1064-D24.9-T1.5 24.9 1.5 (SiO2) Quartz
1064-D25-T2 25 2 (SiO2) Quartz
1064-D25-T3 25 3 (SiO2) Quartz
1064-D25.4-T4 25.4 4 (SiO2) Quartz
1064-D26-T4 26 4 (SiO2) Quartz
1064-D27-T4 27 4 (SiO2) Quartz
1064-D27.9-T4.1 27.9 4.1 (SiO2) Quartz
1064-D30-T1.5 30 1.5 (SiO2) Quartz
1064-D30-T5 30 5 (SiO2) Quartz
1064-D32-T4 32 4 (SiO2) Quartz
1064-D34-T3 34 3 (SiO2) Quartz
1064-D34-T5 34 5 (SiO2) Quartz
1064-D35-T1.5 35 1.5 (SiO2) Quartz
1064-D36-T5 36 5 (SiO2) Quartz
1064-D37-T7 37 7 (SiO2) Quartz
1064-D38-T2 38 2 (SiO2) Quartz
1064-D40-T3 40 3 (SiO2) Quartz
1064-D42-T9 42 9 (SiO2) Quartz
1064-D50-T1.5 50 1.5 (SiO2) Quartz
1064-D50-2.0 50 2.0 (SiO2) Quartz
1064-D50-3.0 50 3.0 (SiO2) Quartz
1064-D55-T1.5 55 1.5 (SiO2) Quartz
1064-D60-T3 60 3 (SiO2) Quartz
