1390 Co2 laser machine

1390 laser engraving machine is the most hot-selling in the market. Co2 laser cutters has large 1300mm by 900mm working area( 35″ x 51″), compact nesting, convenient storage materials.

The knife-shape aluminum heavy strip work of the platform can avoid defective products caused by reflection of backstop while cutting acrylic & wood materials.

If change into honeycomb working table, Co2 laser cutters can used to engrave and cut cloth, fabric, carpet, shoes, etc.

Features:

  • Professional Working Table: Honeycomb or Strip work table for you to choose, use imported stable aluminum material, can meet the needs of diversified laser procession.
  • Taiwan Made Ball Screw Rod: The motorized up and down table adopt Taiwan “Double-win” brand high precision ball screw rod and high accuracy linear running guide rail, can improve the precision and accuracy.
  • Red Light Pointer Function: As laser light is invisible, and the red light pointer of the PVC laser cutter can realize the exact position of the laser beam.
  • Special Front and back running-through design 30-50mm height, Co2 laser cutters can make a unique door for the limitless engraved materials come through from front into the backside, easy to put the material through.
  • Ladder-Shape Drawer Design: Easily collect and getting the cutting object.
  • Laser Beam Stop when Opening Machine Cover: We design a special function to stop the laser beam come out when the operator opens the 130w laser cutter machine’s cover. So that ensure operator won’t be hurt by laser beam, safe for the operator. Other companies don’t have such a design, so it will hurt the operator sometimes when using it.
  • We Do Strict Testing for Each Laser Tube: We will test every laser tube before using them, in order to make sure the performance of the laser tube and it has a nice laser facular.

Application:

  • Available materials: the Co2 laser cutters are widely applied in acrylic, organic glass, wood, MDF, textile, fabric, cloth, leather, paper, EVA materials, PVC plastic, crystal, bamboo, plexiglass, seal, rubber plate, marble, granite, Gum, Ceramics, etc. nonmetal materials.
  • Application Industry: the Co2 laser cutters are widely applied in advertisement, arts and crafts, toys, car, mechanism, electron, as well as in trademarks, embroidery, clothing, and other industries.

Parameters:

  • 130W Power Laser Engraver / 1300mmx900mm (Working Area)
  • RECI W2 Sealed CO2 Laser Tube / S&A-3000 Water Chiller
  • Honeycomb and Blade Workbench / Electric Up&Down Platform
  • Auto Focus / Red Dot Positioning
  • Cover Protection / Auto Blowing
  • Warning Light / Socket of Rotary / Exhaust Fan
Working Area1300x900mm (4 feet*3 feet) Co2 Laser Cutters
Laser Power60w / 80w / 100w / 130w / 150w
Laser TypeHermetic and Detached Co2 Laser Tube
Engraving Speed0-60000mm/min
Cutting Speed0-10000mm/min
Cutting Thickness0-25mm acrylic (Others Determined by Materials)
Repeat Location Accuracy+/-0.0125mm
Driving ModeDC0.8A 24V Stepper Motor
Position SystemRed dot Laser Pointer
InterfaceUSB port transfer
VoltageAC220v/50hz or 110v/60hz
Machine Power900w
Controlling SystemCNC Professional Control System
Support Graphics ModeBMP,HPGL,JPEG,GIF,TIFF,PCX,TAG,DST, PLT,DXF etc.
Cooling ModeCW-3000 Water Cooling (with Protection Function)
Auxiliary DevicesExhaust Fan and Exhaust Pipe
Cutting PlatformProfessional Thickening Strip or Honeycomb Work Table
Power Control ModeLaser Energy Combining Movement Control System
SoftwareProfessional Reader Laser Cutting Software
Operating Temperature0-45C
Operating Humidity5-95%
PackingWooden Box
Guarantee Time12 Months for Machine, 3-10 Months for Laser Tube
OperationVCD Training, Engineer Overseas Available
Machine Size1970mm*1480mm*1250mm

Shipping Dimensions: 2100mm x 1435mm x 1290mm (82.7in x 56.5in x 50.8in)

Gross Weight: 445Kg(981Ib)  Package Wooden Crate

Package Included:

1 x Air Pump

1 x Water Chiller

1 x Set of Inner Hexagon Spanner

2 x Venting Tube

1 x Water Tube

1 x Screwdriver

1 x Power Cord

3 x Clamp

1 x Operation Manual

1 x USB Cable

1 x Ground Wire

1 x Screwdriver

1 x Glue

1 x Adhesive Tape

1 x Network Line

1 x Exhausting Fan

1 x Rotary Axis  (optional)
